High Alumina Castables & Mortars
Alumina Castables
DI ALCAST - A
Super purity high alumina dense castables are being produced at our plant. This castables posses our brand name DI ALCAST - A and are manufactured using a high purity high alumina cement produced and marketed by us.
The number in the brand name denotes the percentage of alumina content in these castables.
Salient Features
- Highest Purity
- Excellent Strength
- Superior Resistance to Temperature
- Resist Fluctuations of Temperature
- Suitable for use in reducing atmospheres
- Service Temp. [ max ] - 1700 0C
| Chemical Properties | |
|---|---|
| A12O3 : | 90% min. |
DI AL - 90 K
| Chemical Analysis | |
|---|---|
| A12O3, % (min) : | Fe2O3, % ( max) : |
| 87.00 | 1.00 |
Size
0 - 0.2 mm
Application
Jointing Mortar for slide gate plate and nozzle.
DI ALCAST - K
Super purity high alumina dense castables are being produced at our plant.
This castables posses our brand name DI ALCAST - K and are manufactured using high purity high alumina cement produced and marketed by us.
The number in the brand name denotes the percentage of alumina content in these castables.
Salient Features
- Highest Purity
- Excellent Strength
- Superior Resistance to Temperature
- Resist Fluctuations of Temperature
- Suitable for use in reducing atmospheres
- Service Temp. [ max ] - 1600 0C
| Chemical Analysis | |
|---|---|
| AL2O3, %, [min] : | Fe2O3, %, [max] : |
| 60.00 | 1.20 |
DI AL -95 H
| Chemical Properties | |
|---|---|
| A12O3 : | 94% min. |
Size
0 - 5 mm
Application
Ramming Mass for fixing Ladle well Block
Castables
High Alumina Dense Castables.
Super purity high alumina dense castables are being produced at our plant.
These castables possess our brand name DI ALCAST and are manufactured using high purity alumina cement, produced and marketed by us.
The number in the brand name denotes the percentage of alumina content in these castables.
Salient Features
- Highest Purity
- Excellent Strength
- Superior Resistance to Temperature
- Resist Fluctuations of Temperature
- Suitable for use in reducing atmospheres
| Properties | ||
|---|---|---|
| DI ALCAST-A-90 | DI ALCAST-K-60 | DI ALCAST-C-50 |
| 1700 oC | 1600 oC | 1600 o |
| Chemical Analysis | |||
|---|---|---|---|
| AL2O3, %, [min] : | 88 | 60 | 50 |
| Fe2O3, %, [min] : | 1.00 | 1.20 | 1.20 |
| CCS, Kg/cm2(Min) | 2.75 | 2.20 | 2.10 |
| Phy. Test BD, g/cc (Min) at 100o C/24 Hrs | 2.75 | 2.20 | 2.10 |
| CCS, Kg/cm2(Min) at 100o C/24 Hrs,at 1450o C/2 Hrs | 550 | 350 | 350 |
| Grain Size, mm,(max) | 0-5 | 0-5 | 0-5 |
| Thermal Analysis | |||
|---|---|---|---|
| PCE, Orton, oC ( Min) | 37/1820oC | 31/1683 oC | 30/1665 oC |
| PLC, %, ( Max) | (+/-) 1.00 | (+/-) 1.50 | (+/-) 1.50 |
| Packaging Storage Life | ||
|---|---|---|
| 50 Kg bags | 50 Kg bags | 50 Kg bags |
| 50 Kg bags | 6 months | 6 months |
High Alumina Mortar
Super purity high alumina mortars are being produced at our plant.
These mortars possess our brand name DI-90-K and DI-95-H and are manufactured using high purity calcined, reactive alumina powder and green chrome oxide.
Salient Features
- Highest Purity
- Superior Resistance to Temperature
- Resist Fluctuations of Temperature
- Suitable for use in reducing atmospheres
| Brand | AI2O3 | Fe2O3 | PCE O.C-C | Grain Size (Max) | Setting | S.T | Sintering Temp |
|---|---|---|---|---|---|---|---|
| DI-90-K Mortar | 88% Min | 0.30% Max | 37 (1820o C) | 0-0.10 | Chemical | 1800o C | 1200o C |
